Metrics

A. Sigmoid

As discussed in the previous chapter, our model outputs logits based on the input data. These logits represent real number mappings from probabilities. Therefore, if we had the inverse mapping we could obtain the original probabilities. Luckily, we have exactly that, in the form of the sigmoid function.

The above plot shows a sigmoid function graph. The x-axis represents logits, while the y-axis represents probabilities.

Note the horizontal asymptotes at y = 0 and y = 1.

Using the sigmoid function (tf.math.sigmoid in TensorFlow), we can extract probabilities from the logits. In binary classification, i.e. output_size = 1, this represents the probability the model gives to the input data being labeled 1. A probability closer to 0 or 1 means the model is pretty sure in its prediction, while a probability closer to 0.5 means the model is unsure (0.5 is equivalent to a random guess of the label's value).

B. Predictions and accuracy

A probability closer to 1 means the model is more sure that the label is 1, while a probability closer to 0 means the model is more sure that the label is 0. Therefore, we can obtain model predictions just by rounding each probability to the nearest integer, which would be 0 or 1. Then our prediction accuracy would be the number of correct predictions divided by the number of labels.

In TensorFlow, there is a function called tf.math.reduce_mean which produces the overall mean of a tensor's numeric values. We can use this to calculate prediction accuracy as the mean number of correct predictions across all input data points.

We use these metrics to evaluate how good our model is both during and after training. This way we can experiment with different computation graphs, such as different numbers of neurons or layers, and find which structure works best for our model.

Time to Code!

The coding exercise for this chapter focuses on obtaining predictions and accuracy based on model logits.

In the backend, we've loaded the logits tensor from the previous chapter's model_layers function. We'll now obtain probabilities from the logits using the sigmoid function.

Set probs equal to tf.math.sigmoid applied to logits.

We can calculate label predictions by rounding each probability to the nearest integer (0 or 1). We'll use tf.math.round to first round the probabilities to 0.0 or 1.0.

Set rounded_probs equal to tf.math.round with probs as the lone argument.

The problem with rounded_probs is that it's still type tf.float32, which doesn't match the type of the labels placeholder. This is an issue, since we need the types to match to compare the two. We can fix this problem using tf.cast.

Set predictions equal to tf.cast with rounded_probs as the first argument and data type tf.int32 as the second argument.

The final metric we want is the accuracy of our predictions. We'll directly compare predictions to labels by using tf.math.equal, which returns a tensor that has True at each position where our prediction matches the label and False elsewhere. Let's call this tensor is_correct.

Set is_correct equal to tf.math.equal with predictions as the first argument and labels as the second argument.

The neat thing about is_correct is that the number of True values divided by the number of total values in the tensor gives us our accuracy. We can use tf.math.reduce_mean to do this calculation. We just need to cast is_correct to type tf.float32, which converts True to 1.0 and False to 0.0.

Set is_correct_float equal to tf.cast with is_correct as the first argument and data type tf.float32 as the second argument.

Set accuracy equal to tf.math.reduce_mean applied to is_correct_float.
